Debugging and Tracing NixOS Modules

window_space

  • Other related post if you haven’t read my previous post on modules, that may be helpful before reading this one:

    • nix-modules-explained

    • This post is my notes following Nix Hour 40. If it seems a little chaotic, try watching one. They are hard to follow if you’re not extremely familiar with the concepts.

    • Nix Hour 40

Nix Code is particularly hard to debug because of (e.g. lazy evaluation, declarative nature, layered modules)

  • The following simple Nix code snippet illustrates a basic NixOS module definition and how options are declared and configured. We’ll use this example to demonstrate fundamental debugging techniques using nix-instantiate.
let
  lib = import <nixpkgs/lib>;
in
lib.evalModules {
  modules = [
    ({ lib, ... }: {
      options.foo = lib.mkOption {
        # type = lib.types.raw;
        type = lib.types.anything;
        # default = pkgs;
      };
      config.foo = {
        bar = 10;
        list = [1 2 3 ];
        baz = lib.mkDefault "baz";
      };
    })
    {
      foo.baz = "bar";
    }
  ];
}

  • In the above code, adding lib to the function arguments isn’t required but if you were to move the module to another file it would fail without it because lib comes from outside of it. So it’s good practice to refer to lib in the modules themselves.

  • You should always assign a type to your options, if you don’t know which type to use you could use raw. raw is a type that doesn’t do any processing. So if you were to assign the entire packages set to the option e.g. default = pkgs; it wouldn’t recurseinto all the packages and try to evaluate them. There is also anything, that is useful if you do want to recurse into the values.

  • The following is an example of how you would run this inside vim/neovim, the rest of the examples will be from the command line:

:!nix-instantiate --eval -A config.foo --strict

Output:

{ bar = 10; baz = "bar"; list = [ 1 2 3 ]; }

To show the difference you could uncomment the raw type and comment the anything type and run the above command again you’ll see that you get an error:

error: The option 'foo' is defined multiple times while it's expected to be
unique

To execute this command on the command line:

nix-instantiate --eval --strict -A config.foo

It will show you the start of a trace. To get the full trace add:

nix-instantiate --eval --strict -A config.foo --show-trace

Example 2

In the previous example, we looked at a simplified module. Now, let’s examine a more realistic scenario involving a basic NixOS configuration file (configuration.nix).

This example will demonstrate how to use nix-instantiate to evaluate an entire system configuration and how --show-trace helps in diagnosing errors within this context.

Consider the following configuration.nix file:

# configuration.nix
{ lib, ... }: {
  boot.loader.grub.device = "nodev";
  fileSystems."/".device = "/devst";
  system.stateVersion = "24.11";
}
  • This configuration snippet sets the GRUB bootloader device, defines a root filesystem, and specifies the expected NixOS state version. To evaluate this entire system configuration, you can use nix-instantiate and point it to the <nixpkgs/nixos> entrypoint, providing our configuration.nix file as an argument. The -A system flag selects the top-level system attribute, which represents the instantiated system configuration.

Run it in with:

nix-instantiate '<nixpkgs/nixos>' --arg configuration ./configuration.nix -A system

Output:

/nix/store/kfcwvvpdbsb3xcks1s76id16i1mc3l5k-nixos-system-nixos-25.05pre-git.drv

Ok, we can see that this successfully instantiates. Let’s introduce an error to trace:

{ lib, ... }: {
  boot.loader.grub.device = "nodev";
  fileSystems."/".device = "/devst";
  system.stateVersion = builtins.genList "24.11" null;
}

Output:

(stack trace truncated; use '--show-trace' to show the full, detailed trace)
error: expected an integer but found null: null

Rerun the command with --show-trace appended:

Or on the command line

nix-instantiate '<nixpkgs/nixos>' --arg configuration ./configuration.nix -A system --show-trace
  • This outputs a much longer trace than the first example. It shows you the file the error occured in and you can see that in this case they are a lot of internal functions. (e.g. at /nix/store/ccfwxygjrarahgfv5865x2f828sjr5h0- source/lib/attrsets.nix:1529:14:)

To show your own error message you could do something like this:

{lib, ...}: {
  boot.loader.grub.device = "nodev";
  fileSystems."/".device = "/devst";
  system.stateVersion = builtins.addErrorContext "AAAAAAAAAAAAAAAAA" (builtins.genList "24.11" null);
}

Run it:

nix-instantiate '<nixpkgs/nixos>' --arg configuration ./configuration.nix -A system --show-trace`

Output:

 … while evaluating the attribute 'value'
     at /nix/store/ccfwxygjrarahgfv5865x2f828sjr5h0-source/lib/modules.nix:770:21:
      769|             inherit (module) file;
      770|             inherit value;
         |                     ^
      771|           }) module.config

   … AAAAAAAAAAAAAAAAA

   … while calling the 'genList' builtin
     at /home/jr/tests/configuration.nix:4:71:
        3|   fileSystems."/".device = "/devst";
        4|   system.stateVersion = builtins.addErrorContext "AAAAAAAAAAAAAAAAA"
         (builtins.genList "24.11" null);
         |                                                                       ^
        5| }

   … while evaluating the second argument passed to builtins.genList

   error: expected an integer but found null: null
  • In the latest nix they actually inverted the error messages so the most relevant parts will be at the bottom.

Example 3

Let’s consider another example, this time demonstrating the definition of configuration options using lib.mkOption within a module structure.

# default.nix
let
  lib = import <nixpkgs/lib>;
in
lib.evalModules {
  modules = [
    ({ lib, ... }: {
      options.ints = lib.mkOption {
        type = lib.types.attrsOf lib.types.int;
      };
      options.strings = lib.mkOption {
        type = lib.types.string;
        # type = lib.types.attrsOf lib.types.string;
        default = "foo";
      };
    })
  ];
}

Instantiate this with:

nix-instantiate --eval --strict -A config.strings

Output:

evaluation warning: The type `types.string` is deprecated.
See https://github.com/NixOS/nixpkgs/pull/66346 for better alternative types.
"foo"
  • Unfortunately you won’t get the same depreciation warning from lib.attrsOf

Below is an interesting way to provide nixpkgs run it on the command line:

export NIX_PATH=nixpkgs=channel:nixpkgs-unstable
echo $NIX_PATH

Output:

nixpkgs=channel:nixpkgs-unstable

The next two commands are to check that after using the above way to provide nixpkgs-unstable that they both point to the same store path, the following command will fetch nixpkgs from the channel above:

nix-instantiate --find-file nixpkgs

Output 1️⃣

/nix/store/ydrgwsibghsyx884qz97zbs1xs93yk11-source

nix-instantiate --eval channel:nixpkgs-unstable -A path

Output: 2️⃣

/nix/store/ydrgwsibghsyx884qz97zbs1xs93yk11-source
  • As you can see both commands produce the same store path

Example 4

In our previous example, we encountered a deprecation warning for lib.types.string. This next example delves deeper into why that type was deprecated and demonstrates the consequences of its behavior, along with the recommended fix.

# default.nix
let
  lib = import <nixpkgs/lib>;
in
  lib.evalModules {
    modules = [
      ({lib, ...}: {
        options.ints = lib.mkOption {
          type = lib.types.attrsOf lib.types.int;
        };
        options.strings = lib.mkOption {
          # type = lib.types.string;
          type = lib.types.attrsOf lib.types.string;
          default = {
            x = "foo";
          };
        };
        config = {
          strings = lib.mkOptionDefault {
            x = "bar";
          };
        };
      })
    ];
  }

Evaluate it with:

nix-instantiate --eval --strict -A config.strings

  • types.string depricated because it silently concatenates strings

  • The above command has two options with the same priority level and evaluates to { x = "foobar"; }

Output:

evaluation warning: The type `types.string` is deprecated. See https://github.
com/NixOS/nixpkgs/pull/66346 for better alternative types.
{ x = "foobar"; }
  • types.str was the replacement for the depricated types.string:
# default.nix
let
  lib = import <nixpkgs/lib>;
in
  lib.evalModules {
    modules = [
      ({lib, ...}: {
        options.ints = lib.mkOption {
          type = lib.types.attrsOf lib.types.int;
        };
        options.strings = lib.mkOption {
          # type = lib.types.string;
          type = lib.types.attrsOf lib.types.str;
          # Sets the value with a lower priority: lib.mkOptionDefault
          default = {
            x = "foo";
          };
        };
        config = {
          strings = lib.mkOptionDefault {
            x = "bar";
          };
        };
      })
    ];
  }

Output:

error:
… while evaluating the attribute 'x'

… while evaluating the attribute 'value'
 at /nix/store/ydrgwsibghsyx884qz97zbs1xs93yk11-source/lib/modules.nix:1148:41:
 1147|
 1148|     optionalValue = if isDefined then { value = mergedValue; } else { };
     |                                         ^
 1149|   };

… while calling the 'foldl'' builtin
 at /nix/store/ydrgwsibghsyx884qz97zbs1xs93yk11-source/lib/options.nix:508:8:
  507|     else
  508|       (foldl' (
     |        ^
  509|         first: def:

(stack trace truncated; use '--show-trace' to show the full, detailed trace)

error: The option `strings.x' has conflicting definition values:
- In `<unknown-file>': "foo"
- In `<unknown-file>': "bar"
Use `lib.mkForce value` or `lib.mkDefault value` to change the priority on any of these definitions.

shell returned 1

Summary

  • So types in the module system aren’t just types in the conventional sense but they also specify the emerging behavior of these values.

  • If we switch the type in the above example to types.lines you get this returned, { x = "foo\nbar"; }

  • mkOptionDefault isn’t typically something you should generally use, instead options have a default setting

  • If you want to make sure that you set a default but if the user specifies it, it shouldn’t get overridden. You should not set it in the following:

options.strings = lib.mkOption {
  type = lib.types.attrsOf lib.types.lines;
  default = {
    x = "foo";
  };
}

Because the above uses mkOptionDefault but instead in under the config attribute like the following:

# ...snip...
options.strings = lib.mkOption {
  type = lib.types.attrsOf lib.types.lines;
  # default = {
    # x = "foo";
  # };
};
config = {
  strings = {
    x = lib.mkDefault "foo";
  };
};
# ...snip...

let
  lib = import <nixpkgs/lib>;
in
  lib.evalModules {
    modules = [
      ({lib, ...}: {
        options.ints = lib.mkOption {
          type = lib.types.attrsOf lib.types.int;
        };
        options.strings = lib.mkOption {
          # type = lib.types.string;
          type = lib.types.attrsOf lib.types.str;
          # Sets the value with a lower priority: lib.mkOptionDefault
          #default = {
          #  x = "foo";
          #};
        };
        config.strings = {
          x = "foo";
        };
      })
      {
        config.strings = {
          y = "bar";
        };
      }
    ];
  }

Output:

  • This works now because there’s no difference between x and y
{ x = "foo"; y = "bar"; }

More Functionality between modules

let
  lib = import <nixpkgs/lib>;
in
  lib.evalModules {
    modules = [
      ({lib, ...}: {
        options.ints = lib.mkOption {
          type = lib.types.attrsOf lib.types.int;
        };
        options.strings = lib.mkOption {
          # type = lib.types.string;
          type = lib.types.attrsOf lib.types.str;
          # Sets the value with a lower priority: lib.mkOptionDefault
          #default = {
          #  x = "foo";
          #};
        };
        config.strings = {
          x = lib.mkDefault "foo";
        };
      })
      {
        config.strings = {
          x = "x";
          y = "bar";
        };
      }
    ];
  }
  • The above command would cause a conflict without the x = lib.mkDefault foo And this is typically what you want to do for defaults and modules in things like nested configuration.

Output:

{ x = "x"; y = "bar"; }

Infinite recursion error

  1. A common pitfall is to introduce a hard to debug error infinite recursion when shadowing a name. The simplest example for this is:
let a = 1; in rec { a = a; }

💡TIP: Avoid rec. Use let ... in Example:

let
 a = 1;
in {
 a = a;
 b = a + 2;
}

We’ll separate the logic for this example, this will be the default.nix this is where having lib defined in your inline modules is helpful because you can just delete the section and paste it into your modules.nix:

# default.nix
let
  lib = import <nixpkgs/lib>;
in
  lib.evalModules {
    modules = [
      ./module.nix
    ];
  }

And in the module.nix:

# module.nix
{ lib, pkgs, ...}: {
  options.etc = lib.mkOption {
    type = lib.types.attrsOf lib.types.path;
    default = { };
    description = ''
      Specifies which paths are is /etc/
    '';
  };

  config._module.args.pkgs = import <nixpkgs> {
    config = {};
    overlays = [];
  };
  config.etc.foo = pkgs.writeText "foo" ''
    foo configuration
  '';
}
  • If you evaluate this with the following you will get an infinite recursion error.
nix-instantiate --eval --strict -A config.etc
  • This happens because --strict evaluates the etc, then it goes into the attrsOf, and the path
nix repl
nix-repl> :l <nixpkgs>
nix-repl> hello.out.out.out

In this example:

  • :l <nixpkgs> loads the Nixpkgs library into the repl environment, making its definitions available.

  • hello refers to the hello package definition within Nixpkgs. Packages in Nixpkgs are defined as derivations.

  • .out is a common attribute name for the main output of a derivation (e.g., the installed package). Some packages, especially those with complex build processes or multiple outputs, might have nested output attributes. In the case of hello, accessing .out.out.out ultimately leads us to the derivation itself.

The key takeaway here is that when you evaluate a package in the nix repl, you’re often interacting with its derivation or one of its output paths in the Nix store. The «derivation ...» indicates that hello.out.out.out evaluates to a derivation – the blueprint for building the hello package. This is in contrast to --eval --strict, which tries to fully evaluate values, potentially leading to infinite recursion if it encounters a derivation that refers back to itself indirectly during attribute evaluation.

Output:

«derivation /nix/store/b1vcpm321dwbwx6wj4n13l35f4y2wrfv-hello-2.12.1.drv»
  • So it recurses through the entire thing and tries to evaluate its string.

So we want to change the command from --eval --strict which is only based on evaluation to at least nix-instantiate which is based on derivations:

nix-instantiate -A config.etc

Output:

warning: you did not specify '--add-root'; the result might be removed by the garbage collector
/nix/store/abyfp1rxk73p0n5kfilv7pawxwvc7hsg-foo.drv
  • We don’t really have a derivation yet for example:
# module.nix
{
  lib,
  pkgs,
  ...
}: {
  options.etc = lib.mkOption {
    type = lib.types.attrsOf (lib.types.attrsOf lib.types.path);
    default = {};
    description = ''
      Specifies which paths are in /etc/
    '';
  };

  config._module.args.pkgs = import <nixpkgs> {
    config = {};
    overlays = [];
  };
  config.etc.foo.bar = pkgs.writeText "foo" ''
    foo configuration
  '';
}

Try to evaluate the above command with nix-instantiate -A config.etc and Nix doesn’t even try to build it. With nested attrsOf

nix repl -f default.nix
nix-repl> config.etc
{
  foo = { ... };
}
nix-repl> config.etc.foo
{
  bar = «derivation /nix/store/abyfp1rxk73p0n5kfilv7pawxwvc7hsg-foo.drv»;
}
  • So config.foo is an attribute set and config.etc.foo is also an attribute set but it’s not a derivation by itself. So nix-instantiate does this one level of recursion here and it would have built foo value if it were a derivation.

Example 5

We’ll use the same module.nix and default.nix from the previous example.

Building More Complex Configurations with Modules In this next example, we’ll focus on a common task in system configuration: managing files within the /etc/ directory. We’ll define a module that allows us to specify the content of arbitrary files in /etc/ and then use a special Nix function to combine these individual file definitions into a single, manageable entity.

We’ll introduce a new option, options.etc, which will allow us to define the content of files within /etc/. Then, we’ll use pkgs.linkFarm to create a derivation that represents the entire /etc/ directory as a collection of symbolic links pointing to the individual file contents we’ve defined. This demonstrates how modules can abstract away the details of creating complex system configurations, providing a declarative and reproducible way to manage even fundamental aspects of the operating system.

Let’s show how we can use Nix modules to declaratively manage the /etc/ directory

# default.nix
let
  lib = import <nixpkgs/lib>;
in
  lib.evalModules {
    modules = [
      ./module.nix
    ];
  }

# module.nix
{
  lib,
  pkgs,
  config,
  ...
}: {
  options.etc = lib.mkOption {
    type = lib.types.attrsOf (lib.types.attrsOf lib.types.path);
    default = {};
    description = ''
      Specifies which paths are in /etc/
    '';
  };
  options.etcCombined = lib.mkOption {
    type = lib.types.package;
    default =
      pkgs.linkFarm "etc"
      (lib.mapAttrsToList (name: value: {
        name = name;
        path = value;
      }) config.etc);
  };

  config._module.args.pkgs = import <nixpkgs> {
    config = {};
    overlays = [];
  };
  config.etc.foo = pkgs.writeText "foo" ''
    foo configuration
  '';
  config.etc.bar = pkgs.writeText "bar" ''
    bar configuration
  '';
}

Run it with:

nix-instantiate -A config.etcCombined

Output:

/nix/store/3da61nmfk546qn2zpxsm57mq6vz6fjx8-etc.drv
  • So we can see that it will instantiate, lets see if it will build:
nix-build -A config.etcCombined

Output:

these 3 derivations will be built:
/nix/store/41yfxq4af1vrs0rrgfk5gc36kmjc7270-bar.drv
/nix/store/abyfp1rxk73p0n5kfilv7pawxwvc7hsg-foo.drv
/nix/store/3da61nmfk546qn2zpxsm57mq6vz6fjx8-etc.drv
building '/nix/store/41yfxq4af1vrs0rrgfk5gc36kmjc7270-bar.drv'...
building '/nix/store/abyfp1rxk73p0n5kfilv7pawxwvc7hsg-foo.drv'...
building '/nix/store/3da61nmfk546qn2zpxsm57mq6vz6fjx8-etc.drv'...
/nix/store/ca3wyk5m3qhy8n1nbn0181m29qvp1klp-etc

nix-build -A config.etcCombined && ls result/ -laa

Output:

/nix/store/ca3wyk5m3qhy8n1nbn0181m29qvp1klp-etc
dr-xr-xr-x - root 31 Dec  1969  .
drwxrwxr-t - root 16 May 15:13  ..
lrwxrwxrwx - root 31 Dec  1969  bar -> /nix/store/1fsjyc2hmilab1qw6jfkf6cb767kz858-bar
lrwxrwxrwx - root 31 Dec  1969  foo -> /nix/store/wai5dycp0zx1lxg0rhpdxnydhiadpk05-foo

  • We can see that foo and bar link to different derivations

  • When trying to figure out which default to use for etcCombined infinisil went to the Nixpkgs Reference Manual. Make sure to go to the correct version.

Or in your local copy of Nixpkgs you could go to nixpkgs/pkgs/build-support/ trivial-builders/default.nix. Then use your editors search feature, with nvim and helix you press /symlinkjoin or /linkFarm hit enter then press n to cycle to the next match. It will bring you to comments and up to date information.

# linkFarm "myexample" [ { name = "hello-test"; path = pkgs.hello; }
# { name = "foobar"; path = pkgs.stack; } ]

Tests

  • How to create a Derivation with passthru.tests outside of Nixpkgs and then run tests available to your package set?
mkdir passthru-tests && cd passthru-tests

Create a default.nix with the following:

# default.nix
let
  pkgs = import <nixpkgs> {};

  package = pkgs.runCommand "foo" {
    passthru.tests.simple = pkgs.runCommand "foo-test" {} ''
      if [[ "$(cat ${package})" != "foo" ]]; then
        echo "Result is not foo"
        exit 1
      fi
      touch $out
  '';
  } ''
    echo foo > $out
  '';
in
package

See if it will build:

nix-build

Try running the test:

nix-build -A passthru.tests

this derivation will be built:
/nix/store/pqpqq9x1wnsabzbsb52z4g4y4zy6p7yx-foo-test.drv
building '/nix/store/pqpqq9x1wnsabzbsb52z4g4y4zy6p7yx-foo-test.drv'...
/nix/store/7bbw2ban0mgkh4d59yz3cnai4aavwvb6-foo-test

Test 2

  • passthru.tests is the convention for defining tests associated with a derivation. The attributes in passthru are preserved and accessible after the derivation is built.
let
  pkgs = import <nixpkgs> {};

  package =
    pkgs.runCommand "foo" {
      passthru.tests.simple = pkgs.runCommand "foo-test" {} ''
        if [[ "$(cat ${package})" != "foo" ]]; then
          echo "Result is not foo"
          exit 1
        fi
        touch $out
      '';

      passthru.tests.version = pkgs.testers.testVersion {
         package = package;
         version = "1.2";
     };

      # pkgs.writeShellApplication
      script = ''
        #!${pkgs.runtimeShell}
        echo "1.2"
      '';
      passAsFiles = [ "script" ];

    } ''
      cp "$scriptPath" "$out"
    '';
in
  package

Try to build it:

nix-build -A passthru.tests

  • testers.testVersion checks if an executable outputs a specific version string.

  • nix-build -A passthru.tests specifically targets the derivations defined within the tests attribute of the main derivation.

these 3 derivations will be built:
  /nix/store/lyz86bd78p7f3yjy1qky6annmggymcwd-foo.drv
  /nix/store/s4iawjy5zpv89dbkc3zz7z3ngz4jq2cv-foo-test.drv
  /nix/store/z3gi4pb8jn2h9rvk4dhba85fiphp5g4z-foo-test-version.drv
building '/nix/store/lyz86bd78p7f3yjy1qky6annmggymcwd-foo.drv'...
cp: cannot stat '': No such file or directory
error: builder for '/nix/store/lyz86bd78p7f3yjy1qky6annmggymcwd-foo.drv'
 failed with exit code 1;
     last 1 log lines:
     > cp: cannot stat '': No such file or directory
     For full logs, run:
       nix log /nix/store/lyz86bd78p7f3yjy1qky6annmggymcwd-foo.drv
error: 1 dependencies of derivation '/nix/store/z3gi4pb8jn2h9rvk4dhba85fiphp5g4z
-foo-test-version.drv' failed to build
error: build of '/nix/store/s4iawjy5zpv89dbkc3zz7z3ngz4jq2cv-foo-test.drv',
 '/nix/store/z3gi4pb8jn2h9rvk4dhba85fiphp5g4z-foo-test-version.drv' failed

Run nix-build with no arguments:

nix-build

nix derivation show /nix/store/lyz86bd78p7f3yjy1qky6annmggymcwd-foo.drv | jq '.[].env'

Output:

{
  "__structuredAttrs": "",
  "buildCommand": "cp \"$scriptPath\" \"$out\"\n",
  "buildInputs": "",
  "builder": "/nix/store/xg75pc4yyfd5n2fimhb98ps910q5lm5n-bash-5.2p37/bin/bash",
  "cmakeFlags": "",
  "configureFlags": "",
  "depsBuildBuild": "",
  "depsBuildBuildPropagated": "",
  "depsBuildTarget": "",
  "depsBuildTargetPropagated": "",
  "depsHostHost": "",
  "depsHostHostPropagated": "",
  "depsTargetTarget": "",
  "depsTargetTargetPropagated": "",
  "doCheck": "",
  "doInstallCheck": "",
  "enableParallelBuilding": "1",
  "enableParallelChecking": "1",
  "enableParallelInstalling": "1",
  "mesonFlags": "",
  "name": "foo",
  "nativeBuildInputs": "",
  "out": "/nix/store/9mcrnddb6lf1md14v4lj6s089i99l5k7-foo",
  "outputs": "out",
  "passAsFile": "buildCommand",
  "passAsFiles": "script",
  "patches": "",
  "propagatedBuildInputs": "",
  "propagatedNativeBuildInputs": "",
  "script": "#!/nix/store/xg75pc4yyfd5n2fimhb98ps910q5lm5n-bash-5.2p37/bin/bash\necho \"1.2\"\n",
  "stdenv": "/nix/store/lgydi1gl5wqcw6k4gyjbaxx7b40zxrsp-stdenv-linux",
  "strictDeps": "",
  "system": "x86_64-linux"
}

nix derivation show /nix/store/lyz86bd78p7f3yjy1qky6annmggymcwd-foo.drv | jq
 '.[].env.buildCommand'

Output:

"cp \"$scriptPath\" \"$out\"\n"
  • raw mode below
nix derivation show /nix/store/lyz86bd78p7f3yjy1qky6annmggymcwd-foo.drv | jq
 '.[].env.buildCommand' -r

Output:

cp "$scriptPath" "$out"
  • It turns out the correct command was passAsFile not passAsFiles but that change wasn’t enough to fix it. passAsFiles expects a list of files, not a single file path. Running nix-build -A passthru.tests failed saying > foo --version returned a non-zero exit code.
let
  pkgs = import <nixpkgs> {};

  package =
    pkgs.runCommand "foo" {
      #passthru.tests.simple = pkgs.runCommand "foo-test" {} ''
      #  if [[ "$(cat ${package})" != "foo" ]]; then
      #    echo "Result is not foo"
      #    exit 1
      #  fi
      #  touch $out
      #'';

      passthru.tests.version = pkgs.testers.testVersion {
        package = package;
        version = "1.2";
      };

      # pkgs.writeShellApplication
      script = ''
        #!${pkgs.runtimeShell}
        echo "1.2"
      '';
      passAsFile = ["script"];
    } ''
      mkdir -p "$out/bin"
      cp "$scriptPath" "$out/bin/foo"
      chmod +x "$out/bin/foo"
    '';
in
  package

Build it:

nix-build -A passthru.tests

Output:

these 2 derivations will be built:
  /nix/store/lqrlcd64dmpzkggcfzlnsnwjd339czd3-foo.drv
  /nix/store/c3kw4xbdlrig08jrdm5wis1dmv2gnqsd-foo-test-version.drv
building '/nix/store/lqrlcd64dmpzkggcfzlnsnwjd339czd3-foo.drv'...
building '/nix/store/c3kw4xbdlrig08jrdm5wis1dmv2gnqsd-foo-test-version.drv'...
1.2
/nix/store/zsbk5zawak68ailvkwi2gad2bqbqmdz9-foo-test-version

Key Takeaways for Debugging NixOS Modules

  • nix-instantiate is Your Friend: Use nix-instantiate to evaluate your NixOS modules and pinpoint errors.

  • Unlock Details with --show-trace: When errors occur, always append --show-trace to get a comprehensive stack trace, revealing the origin of the problem. Remember that in newer Nix versions, the most relevant parts of the trace are often at the bottom.

  • Understand Option Types: Nix option types (raw, anything, string/str, lines, attrsOf) are not just about data types; they also dictate how values are merged and processed within the module system.

  • Be Mindful of mkOptionDefault: While useful in specific scenarios, mkOptionDefault sets a lower priority default. For standard defaults that can be overridden by user configuration, define them directly within the config attribute using lib.mkDefault.

  • Use builtins.addErrorContext: Enhance your custom error messages by providing specific context relevant to your module’s logic using builtins.addErrorContext.

  • Derivations vs. Evaluation: Be aware of the difference between evaluating expressions (--eval --strict) and instantiating derivations (nix-instantiate). Strict evaluation can trigger infinite recursion if it encounters unevaluated derivations with cyclic dependencies during attribute access.

  • Explore with nix repl: The nix repl allows you to interactively explore Nix expressions and the outputs of derivations, providing insights into the structure and values within Nixpkgs.
