Building a Custom NixOS Service with Flakes and Overlays

TL;DR NixOS’s declarative configuration and flakes make it easy to create custom services. This post shows how to build a minimal service using flakes and overlays for a “meow” command

This will be a complete minimal configuration for testing purposes.

Create Project Directory

Start by creating a directory to hold your project, I called mine meow:

mkdir meow && cd meow

Create flake

Create a flake.nix with the following:

# flake.nix
{
  inputs.nixpkgs.url = "github:nixos/nixpkgs/nixos-unstable";
  outputs = { self, nixpkgs, ... }: {
    overlays.default = final: prev: {
      meow = final.writeShellScriptBin "meow" ''
        echo meow
      '';
    };

    nixosModules.default = { pkgs, config, lib, ... }: {
      imports = [ ./nixos-module.nix ];
      # inject dependencies from flake.nix, and don't do anything else
      config = lib.mkIf config.services.meow.enable {
        nixpkgs.overlays = [ self.overlays.default ];
        services.meow.package = lib.mkDefault pkgs.meow;
      };
    };

  };
}

Create Service Module

Next we’ll create the nixos-module.nix in the same directory with the following content:

# nixos-module.nix
{ pkgs, config, lib, ... }:
let cfg = config.services.meow; in {
  options = {
    services.meow = {
      enable = lib.mkEnableOption "meow";
      package = lib.mkOption {
        description = "meow package to use";
        type = lib.types.package;
      };
    };
  };
  config = lib.mkIf cfg.enable {
    systemd.services.meow = {
      description = "meow at the user on the console";
      serviceConfig = {
        Type = "oneshot";
        ExecStart = "${cfg.package}/bin/meow";
        StandardOutput = "journal+console";
      };
      wantedBy = [ "multi-user.target" ];
    };
  };
}

Add nixosConfigurations Output

Lastly, we will add a nixosConfigurations output to the flake.nix

# flake.nix
nixosConfigurations.test = nixpkgs.lib.nixosSystem {
  system = "x86_64-linux";
  modules = [
    self.nixosModules.default
    ({ pkgs, lib, ... }: {
      fileSystems."/" = {
        device = "/dev/sda1";
      };
      boot.loader.grub.enable = false;
      boot.initrd.enable = false;
      boot.kernel.enable = false;
      documentation.enable = false;

      services.meow.enable = true;

      system.stateVersion = "25.05";
    })
  ];
};

nixosConfigurations.test is simply the name we chose for this particular NixOS system configuration.

The final product will look like this:

# flake.nix
{
  inputs.nixpkgs.url = "github:nixos/nixpkgs/nixos-unstable";

  outputs = {
    self,
    nixpkgs,
    ...
  }: {
    overlays.default = final: prev: {
      meow = final.writeShellScriptBin "meow" ''
        echo meow
      '';
    };

    nixosModules.default = {
      pkgs,
      config,
      lib,
      ...
    }: {
      imports = [./nixos-module.nix];
      # inject dependencies from flake.nix, and don't do anything else
      config = lib.mkIf config.services.meow.enable {
        nixpkgs.overlays = [self.overlays.default];
        services.meow.package = lib.mkDefault pkgs.meow;
      };
    };

    nixosConfigurations.test = nixpkgs.lib.nixosSystem {
      system = "x86_64-linux";
      modules = [
        self.nixosModules.default
        ({
          pkgs,
          lib,
          ...
        }: {
          fileSystems."/" = {
            device = "/dev/sda1";
          };
          boot.loader.grub.enable = false;
          boot.initrd.enable = false;
          boot.kernel.enable = false;
          documentation.enable = false;

          services.meow.enable = true;

          system.stateVersion = "25.05";
        })
      ];
    };
  };
}

Build the System Configuration

Then build the system configuration:

nix build .#nixosConfigurations.test.config.system.build.toplevel

If this builds successfully you’ll see a result directory within your meow directory.
I wouldn’t recommend actually switching to this configuration but you could build it to gain familiarity with it. If you were to switch to it you would run ./result/bin/switch-to-configuration
Test in a NixOS Virtual Machine (Recommended):The safest way to see the “meow” output is to build the configuration and then run it in a NixOS virtual machine. You can do this using tools like nixos-generate-config and a virtualization tool (like VirtualBox, QEMU, or GNOME Boxes).
